24V/9KW/11T/CW CLARK TRACTOR SHOVEL 275K 475 475B 475C 675B 3004699 3636821 91014428 902958 1911588 starter motor

FOB Price:: USD 30.00-150.00/Piece

Min.Order Quantity:: 1 Piece/Pieces

Port:: tianjin shanghai ningbo shenzhen heilongjiang heihe manzhouli wulumuqi

Payment Terms:: L/C,D/A,D/P,T/T,Western Union,MoneyGram

Parts number:: STR4302 OR5213 5L4405 4M5615

model:: CLARK TRACTOR SHOVEL 275K 475 475B 475C 675B

origin:: China

brand:: Cummins

Contact Supplier

Product Details
Company Profile

Attribute

Model:	M125R
Teeth:	11T
Power / hp:	9kw
Battery Specifications:	24v

Quick Details

24V/9KW/11T/CW CLARK TRACTOR SHOVEL 275K 475 475B 475C 675B 3004699 3636821 91014428 902958 1911588 starter motor

Replaces Part Numbers & Specifications

Cummins 173184, 3000576, 3004699, 3004700, 300576,

3010125, 3021038, 3063771, 3603868RX, 3603888RX

Delco 10461057, 10471057, 10478863, 10478865, 10478866,

10478878, 10478883, 10478887, 10478888, 10478907,

10478908, 10478909, 10478911, 10478912, 10479126,

10479339, 1109222, 1109285, 1109286, 1109287, 1109288,

OEM: Delco

Type: DD

Voltage: 24 Volts

kW: 9 kW

Rotation: CW

Teeth/Splines: 11 Teeth/Splines

Pinion/Splines OD: 55.9mm / 2.201in

Mounting Hole 1: 0.660” ID Unthreaded

Mounting Hole 2: 0.660” ID Unthreaded

Mounting Hole 3: 0.660” ID Unthreaded

New or Remanufactured: New

Approximate Weight: 79.7 lbs / 36.23 kg

Applications

CLARK DOZER 380 86-81 Cummins KTA-1150 Delco System
CLARK DOZER 380 86-79 Cummins V-1710 Delco System
CLARK DOZER 380 86-79 DD 16V-71N Delco System
CLARK DOZER 380 III 68-67 Cummins NVH-450 Delco System
CLARK DOZER 380 III 72-69 Cummins V-1710C Delco System
CLARK DOZER 380 III 69-67 DD 12V-71N Delco System
CLARK DOZER 380 IIIA 78-73 Cummins V-1710C Delco System
CLARK DOZER 380 IIIA 78-73 DD 16V-71N Delco System
CLARK DOZER 380-2 III 66-65 Cummins NVH-12 Delco System
CLARK DOZER 380-2 III 66-65 DD 12V-71N Delco System
CLARK DOZER 380C III 74-73 Cummins V-1710C Delco System
CLARK DOZER 480 68-65 Cummins VT12-635 Delco System
CLARK DOZER 480 68-65 DD 16V-71N Delco System
CLARK SCRAPER 310 66-65 DD 12V-71T Diesel Delco System
CLARK SCRAPER 310 III 74-65 DD 12V-71T Diesel Delco System
CLARK SCRAPER 310 III H 72-71 DD 12V-71T Diesel Delco System
CLARK SCRAPER 330 III H 74-73 DD 12V-71T Diesel Delco System
CLARK SCRAPER 410 68-67 Cummins VT12-635 Delco System
CLARK SCRAPER 410 74-69 CumminsVTA-1710C Delco System
CLARK TRACTOR SHOVEL 275K 86-81 Cummins KTA-1150 Delco System
CLARK TRACTOR SHOVEL 475 III 68-67 Cummins V12-635 Delco System
CLARK TRACTOR SHOVEL 475 III 72-71 Cummins V12-635C1 Delco System
CLARK TRACTOR SHOVEL 475 III 72-69 Cummins VTA-1710C Delco System
CLARK TRACTOR SHOVEL 475 III 72-70 DD 16V-71 Diesel Delco System
CLARK TRACTOR SHOVEL 475B 86-75 DD 16V-92 Diesel Delco System
CLARK TRACTOR SHOVEL 475B 86-73 VTA-1710C Diesel Delco System
CLARK TRACTOR SHOVEL 475C 86 Cummins 1710 Delco System
CLARK TRACTOR SHOVEL 675 77-70 Cummins VTA-1710C Delco System
CLARK TRACTOR SHOVEL 675B 86-79 Cummins VTA-1710C Delco System
CONST EQUIP CO. MISC. TRUCKS CFA-13 74-71 Cummins NT-310 Delco System
CONST EQUIP CO. MISC. TRUCKS CFA-13 74-71 DD 8V-71 Delco System
CONST EQUIP CO. MISC. TRUCKS CFA-14 70-67 DD 12V-71 Delco System
CONST EQUIP CO. MISC. TRUCKS CFA-15 70-67 DD 12V-71 Delco System
CONST EQUIP CO. MISC. TRUCKS CFA-15 71 DD 8V-71 Delco System
CONST EQUIP CO. MISC. TRUCKS CFA-19 74-71 DD 12V-71 Delco System
CONST EQUIP CO. TOURNAPULS BPA-11 74-67 DD 12V-71 Diesel Delco System
CONST EQUIP CO. TOURNAPULS BPA-5 74-67 DD 12V-71 Diesel Delco System
CONST EQUIP CO. TOURNAPULS BPA-7 74-67 DD 12V-71 Diesel Delco System
CONST EQUIP CO. TOURNAPULS BPA-8 74-67 DD 12V-71 Diesel Delco System
CONST EQUIP CO. TOURNAPULS BPH-5 68-67 DD 12V-71 Diesel Delco System
CUMMINS ENGINES K Series 92-91 K38 Delco SystemCUMMINS ENGINES K Series 90-83 Various Engines Delco System

DRESSER LOADER 550 92-84 Cummins KT-1150 Standard
DRESSER LOADER 560B 92-85 Cummins KT-1150 Standard
DROTT CRAWLER 120C 78-76 DD 12V-71 Delco System
EUCLID SCRAPERS SS-40A 64 Cummins V17-525 Delco System
EUCLID TRACTORS 36LDT 67-60 Cummins Engines Delco System
EUCLID TRACTORS 41LDT 67-61 Cummins VT-12 Delco System
EUCLID TRACTORS 41LDT 67-65 DD 12V-71 Diesel Delco System
EUCLID TRACTORS 44LDT 64 Cummins V17-525 Delco System
EUCLID TRACTORS 44LDT 66-65 DD 12V-71 Diesel Delco System
EUCLID TRACTORS 46LDT 67-64 Cummins VT12-600 Delco System
