AdBlue Tank Assembly China auto parts different type available

Port:
Shanghai, Shenzhen, Guangzhou, etc. (any coastal port in China)
Payment Terms:
T/T,Western Union,MoneyGram
Parts number:
16L 25L 35L
model:
Dongfeng
origin:
China
brand:
Tiema
  • Product Details
  • Company Profile

Attribute

Model: 16A 16B 25 35 35D

Quick Details

AdBlue Tank Assembly
Tank material:MDPE
Working temperature:-40℃~75℃
Working pressure inner:1±0.3bar
Tank and level sensor dimensions available:
Model NO. Dimension
(mm)
Capacity
(L)
Max.Capacity
(L)
Level Sensor Model NO. Performance Parameter
16A 420*200*303 16 20.8 DTK-285 J-SM50076
TV-285 J-S50605
Working temperature:-40℃~75℃
orking pressure inner::1±0.3bar
16B 400*220*301 16 21.7 DTK-285 J-SM50076
TV-285 J-S50333
TV-299 J-S50523
TV3S-464 J-ZM2690
Working temperature:-40℃~75℃
Working pressure inner::1±0.3bar
25 450*220*380 25 27.8 TVD-360 J-S50136 Working temperature:-40℃~75℃
Working pressure inner::1±0.3bar
35 561*200*473 35 41.3 TVN-425 J-SM1160
DTK-471 J-SM2010
DTK-475 J-SM2210
DTK-471 J-S50029
DTK-471 J-S50077
Working temperature:-40℃~75℃
Working pressure inner::1±0.3bar
35D 561*200*473 35 41.3 TZS-471 J-S50272 Working temperature:-40℃~75℃
Working pressure inner::1±0.3bar
38 561*200*473 38 44.1 DTK-471 J-SM2010
DTK-475 J-SM2210
DTKS-464 JZM2670
Working temperature:-40℃~75℃
Working pressure inner::1±0.3bar
