Material: NBR/CPE
Construction: braid(or spiral)
Appearance: black,surface of fabric pattern
Shape:straight tube or moulding tube
Executive standard: SAE J189 GB/T20461
Specification
Nominal size
(mm)
|
I.D. Tolerance
(mm)
|
O.D. Tolerance
(mm)
|
Working strength
(Mpa)
|
(min)Burst
strength(Mpa)
|
Min bend radius
(mm)
|
10
|
10±0.5
|
17±0.5
|
1.72
|
7.0
|
60
|
13
|
13±0.5
|
21±0.5
|
1.72
|
7.0
|
78
|
