Fuel Type: | Diesel fuel |
Dimensions: | 6990mm×2490mm×3250mm |
Gross weight: | 55000kg |
Rated load: | 40000kg |
Drive mode: | 6x4 |
Engine: | Cummins @ LK375 33 |
Transmission: | Fast·Fuller @ 12JSD160TA |
Maebashi: | 7t |
Rear axle: | 16t |
Wheelbase: | 3400mm+1300mm |
Cab: | T380 flat-roof LHD (2 sleeper) |
Tire: | 315/80R22.5 |
Specifications
Overall Parameters |
||||
Truck model |
STQ4251L7Y9S33 |
Wheel base |
3400mm+1300mm |
|
Rated towing capacity |
40000kg |
Overall dimension(L×W×H) |
6990mm×2490mm×3250mm |
|
Gross Combination Mass(GCM) |
55000kg |
Max economical speed |
85km/h @ 1500rpm |
|
|
||||
Cabin |
||||
Cabin Model |
T380 high-roof LHD (2 sleeper) |
Air Condition |
with Merit Brand A/C |
|
|
||||
Engine |
||||
Brand @ Model |
Cummins @ LK375 33 |
Intake way |
Turbo inter-cooling |
|
Rated power & speed |
375HP (275KW) & 2000rpm |
Max. torque |
1600N.M |
|
Engine type |
in-line,4-stroke,water-cooled |
Bore x Stroke |
116.5mmx148mm |
|
Displacement |
6 cylinders,9.5L,diesel |
Green Band |
1100~1500RPM |
|
Emission standard |
Euro-Ⅲ |
Fuel injection pump |
Mechanical Pump |
|
|
|
|
|
|
Gearbox |
||||
Brand @ Model |
Fast·Fuller @ 12JSD160TA (aluminum alloy body) |
|||
Type |
Manual,12 forward gear,2 reverse gear,rated input torque 1600N.M |
|||
Gearbox ratio |
Forward:12.10,9.41,7.31,5.71,4.46,3.48,2.71,2.11,1.64,1.28,1.00,0.78 |
|||
|
|
|||
|
||||
Chassis Frame & Suspension System |
||||
Chassis frame |
P610L high strenth steel,frame breadth 300mm,double-deck(8mm+4mm) |
|||
Front axle |
5T Dongfeng Dana 153 front axle x1 |
|||
Rear axle |
13T Dongfeng Dana 462 single-reduction rear axle x2,default ratio:4.44 |
|||
Front suspension |
Number/Thickness of leaf spring: 3/22mm |
|||
Rear suspension |
Number/Thickness of leaf spring: 4/30mm |
|||
|
||||
Bodyworks |
||||
Tire & Wheel Rim |
315/80R22.5 aoelus tubeless tire x11 |
|||
Fuel Tank |
600L aluminium |
|||
Air Filter |
Standard |
|||
Fifth Wheel |
dongfeng 90# fifth wheel |
|
